17″ Multi-Touch Monitor

DM-1732-38B

Zoom17-touch-monitor-1419353787-png
$519.00 (Excl. Sales Tax)
Shipping *
How many ?

0% Complete

  • Description
  • Product Documentation
  • Product Specifications

Description

  • Using NEC LED Monitor Model E172M-BK
  • Projected Capacitive Multi-Touch
  • Integrated Speakers
  • 3-year limited warranty
  • TAA Compliant

Product Documentation

  • PDF Spec Sheet
  • 17" LCD Touch Monitor (DM-1700-38B Model) Manual
  • Technical Drawing

Product Specifications

Size 17 inch Diagonal
Type LED Backlit Display
Touch Technology Projected Capacitive (PCAP) 10-Point Multi-Touch
Brightness (typical) 250 cd/m2
Contents of Packaging User's manual, Power cord, Setup Sheet, OWT Driver CD
Contrast Ratio (typical) 1000:1
Dimensions (WxHxD) Net (w/ stand): 14.5" x 14.1-16.1" x 9.1" 368mm x 358-408mm x 230 mmNet (w/o stand): 14.5" x 12.6" x 2.4" / 368mm x 320.5mm x 61mm
Display Colors More than 16 million (Dependent upon display card used)
Input Video Signal ANALOG: 0.7 Vp-p/75 Ohms
Input DisplayPort, HDMI and VGA 15 pin D-sub
Limited Warranty 3 Years Parts and Labor including Backlight
Operating Altitude 3048m / 10,000 ft.
Operating Humidity 30-80%
Operating Temperature 5-35°C / 41-95°F
Pixel Pitch 0.264mm
Power Consumption On: 12W Power saving mode: 0.4W
Resolutions Supported 1280 x 1024 Native Resolution
Storage Altitude 12,192m / 40,000 ft.
Storage Humidity 10-85%
Storage Temperature -10-60°C / 14-140°F
Sync Separate Sync: TTL Level (positive/negative)
Synchronization Range (Automatic) Horizontal: 31.5 kHz to 81 kHz (Analog/Digital) Vertical: 56 Hz to 75 Hz
VESA Hole Configuration Spec. 100mm x 100mm
Viewing Angle 160° Vert., 170° Hor. (80U/80D/85L/85R) @ CR>5
Voltage Rating AC 100-120V/AC 220-240V
Weight Net: 14.3 lbs./6.5 kg Net (without stand): 8.8 kg./4.0 kg
Additional Features Tilt, No Touch Auto Adjust, cable management,, NaViSet software, digital smoothing, digital controls, user (OSD) controls, AccuColor color control, DDC/CI, VESA DPMS power management, ISO 13406-2 Class II
Response Time (typical) Rapid Response (5ms)
Categories Desktop Touch Monitors , Multi-Touch Monitors
